Cambridge breakthrough in brain-inspired chips could cut AI energy use by 70%
Researchers at the University of Cambridge have developed a new nanoelectronic device that could significantly reduce the energy demands of artificial intelligence (AI) hardware by mimicking the way the human brain processes information.
The breakthrough centres on a novel form of hafnium oxide that functions as a highly stable, low-energy memristor — a component designed to replicate how neurons connect and communicate. The findings, published in Science Advances, point to a potential step-change in how AI systems are built and powered.
Current AI architectures rely on conventional semiconductor chips that continuously transfer data between memory and processing units. This back-and-forth movement is highly energy intensive, a growing concern as global AI adoption accelerates across sectors.
The Cambridge team’s approach draws on neuromorphic computing, a brain-inspired model that integrates memory and processing in the same location. This could cut energy consumption by up to 70%, while also enabling systems to learn and adapt more efficiently.
“Energy consumption is one of the key challenges in current AI hardware,” said Dr Babak Bakhit, lead author from Cambridge’s Department of Materials Science and Metallurgy. He added that next-generation devices must combine ultra-low power operation with stability and the ability to switch between multiple states.
Traditional memristors typically rely on conductive filaments within metal oxides to function. However, these filaments can behave unpredictably and often require high operating voltages, limiting their scalability.
In contrast, the Cambridge researchers engineered a hafnium-based thin film incorporating strontium and titanium, produced using a two-step growth process. This created nanoscale ‘p-n junctions’ at the interface between layers, enabling the device to switch states by modulating an energy barrier rather than forming filaments.
According to Bakhit, this interface-driven mechanism delivers far greater consistency. “Filamentary devices suffer from random behaviour,” he said. “But because our devices switch at the interface, they show outstanding uniformity from cycle to cycle and from device to device.”
The devices demonstrated switching currents around a million times lower than some conventional alternatives, while also supporting hundreds of stable conductance levels — a critical feature for analogue, in-memory computing.
Laboratory tests showed the memristors could endure tens of thousands of switching cycles and retain programmed states for up to a day. They also replicated key biological learning behaviours, including spike-timing dependent plasticity, where neural connections strengthen or weaken based on signal timing.
Despite the promise, challenges remain. The fabrication process currently requires temperatures of around 700°C, exceeding typical semiconductor manufacturing limits. The team is now working to lower this threshold to enable integration into commercial chip production.
“If we can reduce the temperature and put these devices onto a chip, it would be a major step forward,” Bakhit said.
A patent application has been filed through Cambridge Enterprise, with the research supported by organisations including UK Research and Innovation and the Royal Society.
